Hills Antenna FB607174 48mm x 1250 Ground Mount FB607174

Description

The Hills Antenna FB607174 is a 48mm x 1250 ground mount that can be used as an alternative to a roof mount. It is suited to 80cm satellite dishes only.

Features:

• The installation site should be chosen so that the dish will not be subjected to accidental impacts that would disrupt its alignment.
• The satellite dish should be mounted so that its centre is no higher than 90 cm above the top of the concrete footing.
• Embedment depth of the mounting tube should be no less than 80% of the depth of the concrete footing.
• Insert the reinforcing rod into the base of the mast prior to concreting.
• The required size of the concrete footing is dependent on the soil type and design wind speed at the installation site.
• The use of a rapid setting concrete is recommended.
• Foxtel Approved IPL # FB607174
