MATCHMASTER N-TYPE PLUG SPRING FINGER CLAMP LMR/LL400 : 56MM-NM400C

Description

Product Summary

The N500P is a Spinner brand N-Plug connector for E500 50 Ohm half-inch corrugated cable. Terminate half-inch cable to inputs from cellular, other communication antennas or when linking longer cable runs in RF networks. The N500P is a multi-fit connector designed for use with many reputable brands of 50 Ohm half-inch cables.

Features and Benefits

Used to connect half-inch cable to antenna ports or other communications links

Frequency range DC to 6GHz

Made from copper alloy metal parts with a combination of different plating’s

PTFE/PE insulation with silicone rubber, EPDM sealing

IP68 per EN 60529 (barrier and mating face sealed)

Reliable, robust and durable

Specifications

Interface Type: N Plug (50 Ω) per IEC 61169-16

Version: MultiFit

Frequency Range: DC to 6 GHz

VSWR, Max. / typ.: 1.02 @ DC to 1.0 GHz; 1.03 @ 1.0 to 2.7 GHz; 1.08 @ 2.7 to 3.8 GHz; 1.10 @ 3.8 to 6.0 GHz

Inner Conductor Material / Surface Finish: Copper Alloy / Silver Plated

Outer Conductor Material / Surface Finish: copper alloy / CuSnZn plated

Other Metal Parts / Surface Finish: Copper Alloy / Sn Plated; Copper Alloy / CuSnZn Plated; Copper Alloy / nickel Plated

Insulation: PTFE, PE

Sealing: Silicone Rubber, EPDM

IP Protection Level: IP68 per EN 60529 (Barrier and mating face sealed)

Cable compatibility: SPINNER – SPINNERFlex™ LF1/2″-50; Acome – HPL50-1/2F; Andrew – LDF4-50A; Draka – RFA 1/2″-50; Eupen – EC4-50; Hansen – RF 50 1/2″; Hengxin – HCAAY-50-12; Leoni – FlexLine 1/2″ R; LS Cable – HFC 12D Flexible Foam; RFS

Installation instructions / Product manual: M32130

Weight, approx.: 80g
