Major Tech Auto DMM, Temp, Capacitance, Hz MT24

Description

The MT24 is a compact meter with double moulded rubber housing and meets the International Standard IEC-61010-1 CAT lll 600V. The large LCD display screen has a white backlight for use in arduous areas. This meter is a very economical tester ideally suited for everyday use by electricians, electronic technicians as well as the air conditioning industry. The MT24 is an autoranging multimeter with the option of manual override, and has a 6000 count LCD display with a 61 segment analogue bargraph. This meter offers features of MIN/MAX recordings, Data Hold, Frequency measurement with Duty Cycle, Capacitance measurement of up to 4000?F and resistance of 60M?. It has the added function of temperature measurement in either ?C or ?F, with a range from -20?C up to 760?C. An adaptor is supplied which converts the 4mm input to accept K-Type thermocouples.

CAT III 600V and CAT II 1000V

Measures AC and DC Voltage to 1000V

MIN/MAX Recordings

Auto Range with Manual Overrid

Frequency measurement to 10MHz

-20?C to 760?C Temperature measurement

Capacitance to 4000?F

Data Hold

Duty Cycle

6000 Count LCD with bargraph

Auto Power Off

Overmould rubber housing

Integrated Test Lead Holder

Back light for dimly lit areas

SPECIFICATIONS

*Function: DC Voltage Range: 600.0mV ? 1000V Resolution: 0.1mV Accuracy: ?(1.2% + 2 Digits)

*Function: AC Voltage Range: 6.000V ? 1000V Resolution: 0.1mV Accuracy: ?(1.5% + 3 Digits)

*Function: DC Current Range: 6A ? 10A Resolution: 1mA Accuracy: ?(2.5% + 5 Digits)

*Function: AC Current Range: 6A ? 10A Resolution: 1mA Accuracy: ?(3.0% + 5 Digits)

*Function: Duty Cycle Range: 0.1 to 99.90% Resolution: 0.001 Accuracy: ?(1.2% + 2 Digits)

*Function: Resistance Range: 600.0? ? 60.00M? Resolution: 0.1? Accuracy: ?(1.2% + 2 Digits

*Function: Frequency Range: 9.999Hz ? 10MHz Resolution: 0.001Hz Accuracy: ?(1.2% + 3 Digits)

*Function: Capacitance Range: 40.00nF ? 4000?F Resolution: 10pF Accuracy: ?(3.0% + 5 Digits)

*Function: Temperature Range: -20?C to 760?C Resolution: 1?C Accuracy: ?(3.0% + 5?C)

*Function: AC Bandwidth Range: 50Hz to 60Hz

*Function: Digital Display Range: 6000

*Function: Continuity Range: Yes

*Function: Diode Test Range: Yes

*Function: Overrange Indication Range: Yes

*Function: Input Impedance Range: 7.8M? VDC & 7.8M? VAC

*Function: Min Max Range: Yes

*Function: Data Hold Range: Yes

*Function: Enclosure Range: Double moulded

*Function: Low Battery Indication Range: Yes

*Function: Battery Range: 9V

*Function: Weight Range: 255g

*Function: Dimensions Range: 150 x 70 x 48mm

*Function: Safety Specs Range: IEC61010-1 CAT III 600V

Accessories:

Type-K Temperature Probe

Type-K Adaptor

9V Battery

Instruction Manual
