Watchguard PIR with Glass and Shock Detection ALH-PIRGS

Description

The sensor analyses two sequential signals of different frequencies allowing detection of both shock signal and glass breakage preventing false alarms. The detector can be mounted on a wall providing up to 15m movement and 10m glass break coverage, allowing you to protect several windows at once.

Product features:

• Quad (Four element) pyrosensor

• Two independent relay outputs for GLASS/SHOCK and PIR alarm signals

• Adjustable PIR / GLASS / SHOCK sensitivity

• Automatic temperature compensation

• Height installation: 1.8 ~ 2.4m

• Pet immunity up to 25Kg (active below 1m)

• PIR Range: 15m

• Glass Break Range: 10m

• EMI Protection: 50,000V

• Contacts of Alarm: N.C.

• Dimensions: 120 x 65 x 45mm

• Input Voltage: 12V

SPECIFICATIONS

Type: Motion Sensor

Warranty (Years): 2

Shipping Weight and Dimensions

Includes product and packages

Width: 43mm

Height: 65mm

Depth: 120mm

Weight: 0.10kg
