VIP Vision Ultimate 64 Channel Network Video Recorder (384Mbps) NVR64ULT8S

$2,382.86 inc GST

20 in stock

fast-delivery

Fast Shipping

On All Orders

worker

15+ Years

Industry Experience

Australian Company

Owned & Operated

30-days

Easy Returns

30 Days Peace Of Mind

Description

The VIP Vision NVR64ULT8S is a 64 channel network video recorder, designed as a high performance, high capacity, professional IP surveillance solution for enterprise applications. This NVR offers native Ultra HD broadcast-quality image performance and an internal DVD-RW burner and hot-spare RAID support.

Product features:
• Record beyond Ultra HD up to 12.0MP (4000 x 3000)
• 64CH NVR with no Power over Ethernet ports
• 384Mbps incoming bandwidth with H.265 support
• Decode up to 16 channels at 1080p (30fps)
• 8 x SATA ports up to 10TB, max. 80TB HDD capacity
• Supports easy hot-swap hard drive access
• High performance Intel quad core processors
• Native Ultra HD live view on 4K monitors via HDMI
• Smart tracking and intelligent video analytics
• RAID HDD optimisation & power redundancy avail.
• Live view, playback & record via your phone/tablet

This NVR requires external Power over Ethernet switches.

Specifications

General
Main Processor: Intel® Quad Core Processors
Operating System: Embedded Linux
Video Input: 64 channels
Two-way Talk: 1 channel input, 1 channel output, RCA
Interoperability: ONVIF 2.4, CGI conformant
Display
Video Output: 2 x HDMI, 1 x VGA
Display Resolution: Configurable from 3840 x 2160 to 1024 x 768
Display Split: 1/4/8/9/16/25/36/64, Extra display: 1/4/8/9/16
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Recording Resolution: Configurable from 12.0MP (4000 x 3000) to CIF (352 x 288)
Incoming Bandwidth: 384Mbps
Decoding Capacity: 16 channels: 1080p (30fps)
Video Compression: H.265 / H.264 / MJPEG
Bit Rate: 16kbps ~ 20Mbps per channel
Record Modes: Manual / Schedule (Regular [Continuous], Motion Detection, Alarm) / Stop
Record Interval: 1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s
Features
Alarm Input / Output: 16 channels input / 8 channels relay output (N.O/N.C)
Trigger Events: Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips
Video Detection: Motion Detection, Motion Zones: 396 (22 x 18), Video Loss & Tampering
Playback Sync: 128Mbps (RAID 5 mode) / 64Mbps (single HDD mode)
Search Modes: Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search
Backup Modes: USB Device / Network / eSATA Device / Internal SATA burner
Network
Ethernet: 2 x RJ-45 ports (10/100/1000Mbps)
Power over Ethernet: N/A
Network Functions: HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, P2P
Optical Interface: N/A
Max. User Access: 128 users
Remote View: iOS (iPhone, iPad) / Android devices
Storage
Internal HDD: 8 x SATA ports up to 10TB, max. 80TB HDD capacity
HDD Modes: Single disk, RAID 0/1/5/6/10/50/60 (Global hot-spare support)
USB Interface: 4 ports: 2 x USB3.0 / 2 x USB2.0
Auxiliary Inputs: 1 x RS232 / 1 x RS485 / 1 x eSATA / 1 x Mini SAS
Environment
Power Supply: 100VAC ~ 240VAC, 50 ~ 60 Hz
Power Consumption: <20W (Without HDD)
PoE: No
Operating Environment: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Rackmountable: Yes (included)
Rackmount Units: 2U
Dimensions: 451 x 440 x 95mm
Weight: 9kg (without HDD)
Warranty (Years): 4

Shipping Weight and Dimensions

Includes product packaging

Width: 571 mm
Height: 225 mm
Depth: 571 mm
Weight: 9.62 kg
