VIP Vision Professional AI 32 Channel Network Video Recorder with ePoE (320Mbps) NVR32PRO16P-I

Description

High-Performance AI Surveillance Built for Demanding Sites

The VIP Vision Professional AI 32 Channel Network Video Recorder is designed for large-scale surveillance environments where clarity, speed, and intelligent monitoring matter. With support for up to 32 IP channels and ultra-high recording resolution up to 16.0MP, this NVR delivers sharp, detailed footage across complex sites such as commercial buildings, warehouses, retail precincts, and multi-dwelling developments.

Powered by advanced AI processing, it enables real-time face recognition, people and vehicle detection, and intelligent search capabilities that dramatically reduce time spent reviewing footage. With up to 320Mbps incoming bandwidth and H.265+ compression, you get smoother video handling, efficient storage use, and reliable performance even under heavy camera loads. Dual HDMI outputs including 4K support ensure crisp live viewing across control rooms and security stations.

Reliable Compliance, Storage Security & Intelligent Protection

Built for professional-grade installations, this NVR is engineered for reliability and long-term operational security. It supports ONVIF 2.4 compatibility, ensuring seamless integration with a wide range of compliant IP cameras and existing surveillance systems. Embedded Linux OS provides stable, secure performance suited for 24/7 monitoring environments.

Advanced AI-powered perimeter protection helps detect and classify humans and vehicles with precision, supporting up to 16 channels of intelligent detection when paired with compatible AI cameras. Face recognition technology allows database management of up to 100,000 faces, helping identify known individuals, flag strangers, and trigger alerts instantly to connected devices.

With flexible recording modes including motion detection, scheduled recording, alarms, and IVS events, this system ensures critical moments are captured without unnecessary storage waste. Up to 56TB of storage capacity across 4 SATA drives provides long-term footage retention for compliance, audits, and incident review.

Built for Trade Efficiency, Fast Deployment & Project Control

Designed with electricians and security installers in mind, this recorder simplifies deployment on busy job sites. The integrated 16-port PoE switch (including ePoE support) reduces the need for additional network hardware, saving installation time and reducing system complexity. Long-distance ePoE capability also supports flexible camera placement across larger sites.

Remote access via iOS and Android allows contractors and clients to monitor systems on the go, while multi-user support (up to 128 users) enables scalable access control across teams and stakeholders. With rackmount-ready design and intuitive interface tools like event search, metadata filtering, and playback syncing, day-to-day system management becomes faster and more efficient.

For contractors managing tight deadlines, multiple projects, or large commercial installs, this NVR delivers a dependable, all-in-one surveillance backbone that keeps jobs moving and clients protected.

Key Specs

• Video Input: 32 channels
• Recording Resolution: Up to 16.0MP (4920 x 3264)
• Incoming Bandwidth: 320Mbps (160Mbps with AI enabled)
• Video Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
• Decoding Capacity: 4 × 8MP (30fps) or 16 × 1080p (30fps)
• Storage: 4 × SATA III, up to 14TB each (max 56TB)
• PoE Ports: 16 (IEEE802.3af/at), 8 x ePoE supported
• Video Outputs: 2 × HDMI, 1 × VGA
• Operating System: Embedded Linux
• Two-way Audio: 1 input / 1 output (RCA)
• Alarm Inputs/Outputs: 16 inputs / 6 relay outputs
• Network: 1 × RJ45 (10/100/1000Mbps)
• User Access: Up to 128 users
• AI Face Recognition: Up to 16 channels (Ultimate AI cameras)
• Perimeter Protection: Up to 16 channels (human/vehicle detection)
• Remote Access: iOS & Android supported
• Rackmount: Yes (1.5RU included)

Ideal For

• Commercial security installations and CCTV upgrades
• Multi-residential apartment complexes and strata properties
• Warehouses, logistics hubs, and industrial facilities
• Retail centres and shopping precincts
• Construction sites requiring perimeter monitoring
• Electrical contractors handling large-scale security projects
• Facilities maintenance and building management teams

Shipping Weight & Dimensions

• Width: 530 mm
• Height: 210 mm
• Depth: 500 mm
• Weight: 6.94 kg (packaged)
