Insulated Mat Class 0 1000V AS/NZS IEC 61111 – Volt Safety MAT-0

Description

Electrical Insulation for Ground Isolation

The Volt Safety MAT-0 Insulated Mat Class 0 1000V provides an insulating layer between the operator and ground to help protect workers from ground potential during electrical work. Designed for professional environments, this electrical insulated mat is manufactured from flexible EPDM rubber and features an anti-slip finish on both sides for practical workplace use.

With a Class 0 rating and 1000V specification, the mat is manufactured to AS/NZS IEC 61111 and IEC 61111 requirements. Its 2.2mm thickness provides a practical insulating surface while maintaining flexibility for handling, positioning, and storage. The grey finish provides a neutral appearance suitable for electrical work areas.

Flexible EPDM Construction and Anti-Slip Surface

The MAT-0 uses EPDM rubber designed to maintain flexibility while providing protection against ozone cracking. The material is also resistant to extremely low temperatures, making it suitable for applications where environmental conditions may vary.

An anti-slip finish is incorporated on both sides of the mat to help provide secure positioning during use. The standard 1m x 1m format offers a convenient work surface, while custom sizing up to 1m x 10m is available on request for applications requiring greater coverage.

Practical Options for Different Work Areas

The insulated mat can be supplied in custom dimensions to suit specific work areas, with a 1m x 10m mat roll also available. A dedicated roll-up style bag is available to help protect the mat during storage and extend its usable lifetime. For pillar-mounted applications, the Pillar Box Mat option is designed to fit around a pillar while providing an isolated surface for the worker.

Key Specs

• Product: Volt Safety MAT-0
• Size: 1m x 1m
• Class: Class 0
• Voltage: 1000V
• Thickness: 2.2mm
• Weight: 3.5kg per metre
• Material: EPDM rubber
• Colour: Grey
• Surface: Anti-slip finish on both sides
• Temperature resistance: C – Resistant to extremely low temperatures
• Standards: AS/NZS IEC 61111, IEC 61111
• Custom sizing: Up to 1m x 10m on request

Ideal For

• Licensed electricians performing electrical work
• Electrical maintenance and service environments
• Commercial and industrial electrical applications
• Work areas requiring isolation from ground potential
• Applications requiring a Class 0 1000V insulating mat
• Installations requiring custom mat dimensions
• Professionals seeking products manufactured to AS/NZS IEC 61111
