CABAC BI-METAL CIRC BREACHK LUG 120MM2 10MM STUD BL120CB-10 x 1/EACH

Description

Strong Bi-Metal Connection for High-Current Terminations

When terminating large aluminium conductors to copper circuit breaker terminals, a reliable transition point is critical. The CABAC Bi-Metal Circuit Breaker Lug 120mm² 10mm Stud (BL120CB-10) is designed to create a strong, electrically sound connection using a friction-welded joint that bonds aluminium and copper components together. This construction ensures dependable conductivity while reducing the risk of thermal stress at the connection point. The lug is specifically suited to 120mm² conductors and a 10mm stud, making it a practical choice for switchboards, distribution systems, and heavy-duty circuit breaker terminations where a secure connection is essential.

Built for Reliable, Trade-Grade Installations

Consistency and compliance matter on every job. These CABAC bi-metal lugs are manufactured using a friction welding process, producing a robust joint that maintains electrical integrity between dissimilar metals. The lug barrel contains crimping compound and is sealed with a cap, helping protect the connection and improve conductivity when the conductor is crimped. Installers can also quickly identify the correct crimp points thanks to clearly marked AF crimping positions on the barrel, helping ensure accurate and repeatable terminations. Designed for use with aluminium conductors and copper circuit breaker terminals, the lug allows electricians to confidently transition between conductor materials while maintaining a durable and electrically sound joint.

Faster Terminations on Busy Project Sites

On commercial and industrial projects, efficient installations keep crews moving and projects on schedule. This CABAC lug is designed with practical installation features that support quick and reliable terminations in the field. Crimping from the palm end forces compound into the conductor strands, helping create a consistent connection during installation. The sealed barrel helps keep the compound contained until crimping, reducing preparation time and simplifying the process on site.

For electricians managing switchboard builds, distribution upgrades, or large cable terminations, reliable components like this reduce rework risk and help maintain installation quality across multiple projects.

Key Specs

• Brand: CABAC

• Type: Bi-metal circuit breaker lug

• Conductor Size: 120mm²

• Stud Size: 10mm

• Model: BL120CB-10

• Manufactured using friction welding process

• Suitable for aluminium conductor and copper circuit breaker terminals

• Crimping compound in barrel and sealed with cap

• AF crimping positions clearly marked on barrel

Ideal For

• Terminating aluminium conductors to copper circuit breaker terminals

• Switchboard and distribution board installations

• Commercial and industrial electrical projects

• Electrical contractors working with large conductor terminations

• Maintenance and upgrade work on existing distribution systems
