CABAC AL SECTOR 3 CORE 185MM2 ALS185/3-12 x 1/EACH

Description

Built for Solid Performance on Site

Designed specifically for solid sector 3-core aluminium cables, this CABAC Aluminium Sector Lug delivers a secure, low-resistance connection you can rely on in demanding installations. Manufactured from 99.6% pure electrical-grade aluminium, it provides excellent conductivity while remaining fully annealed for easier crimping and consistent results in the field. The barrel comes pre-filled with jointing compound and sealed with a cap, helping reduce oxidation and contact resistance from day one. With three indent crimps required, the clearly marked crimping sequence supports accurate installation using standard Australian tooling—saving time and minimising rework on site.

Compliance You Can Trust

When compliance matters, this lug ticks the boxes. It’s designed to suit solid sector aluminium conductors dimensioned to BS3988-1970 and is compatible with common nest and indent dies used across Australia. CABAC aluminium sector lugs are chemically treated to inhibit corrosion and maintain long-term electrical performance, even in challenging environments. They comply with a wide range of international and local standards, giving peace of mind for residential, commercial, and industrial projects where inspections and certifications are non-negotiable.

Trade-Ready Convenience That Saves Time

This 185mm² aluminium sector lug with a 12mm stud hole is supplied individually packed, making it easy to store, transport, and grab what you need without waste. Off-the-shelf availability keeps projects moving, while the option to request alternative sizes or stud holes supports non-standard jobs without chasing multiple suppliers. For contractors working to tight deadlines, having a trade-grade lug that installs cleanly, meets standards, and is readily available helps reduce downtime and keeps crews productive across multiple sites.

Key Specs

• Nominal Conductor Size: 185mm²

• Core Type: Solid sector, 3 core only

• Stud Size: 12mm

• Conductive Material: Aluminium (99.6% pure)

• Tensile Strength: 110 MPa

• Ductile Rating: 28%

• Final Metal State: Fully annealed

• Resistivity: 2.6 micro-ohm cm (max)

• Conductivity: 61.8% IACS (min)

• Operating Temperature: -20°C to +140°C

Ideal For

• Licensed electricians terminating large aluminium feeders

• Commercial and industrial switchboard installations

• Maintenance and upgrade work using solid sector aluminium cables

• Projects requiring compliant, corrosion-resistant aluminium lugs

• Contractors needing reliable, off-the-shelf trade components
