CABAC AL LUG 40MM2 12MM STUD CCT AL40-12-CCT x 1/EACH

Description

Built for Performance on CCT Aluminium Conductors

Designed specifically for CCT applications, this CABAC Aluminium Lug 40mm² delivers dependable electrical performance where overhead and covered conductors are used. The heavy-duty, thick-wall barrel is engineered to handle fault current conditions without compromise, helping reduce the risk of hot joints and rework on critical connections. Supplied pre-filled with jointing compound and capped, it speeds up termination while ensuring consistent conductivity across the connection—ideal when you need clean, repeatable results on site using standard hexagonal crimp dies.

Proven Reliability & Standards Compliance

Manufactured from solid 99.6% pure electrical-grade aluminium using a forging process, this lug avoids the internal imperfections commonly found in cast alternatives. The result is long-term electrical reliability and improved joint integrity over the life of the installation. Tin plating helps minimise corrosion and lowers contact resistance during crimping, making it suitable for demanding outdoor and utility environments. Fully compliant with major international standards including AS/NZS 4325 Part 1, this lug supports compliant installations across Australian projects where CCT conductors are specified by authorities.

Trade Convenience That Saves Time on the Job

For electricians and contractors working to tight schedules, these cabac aluminium lugs are built for efficiency. Clear sizing, consistent quality, and trade-grade construction reduce installation errors and callbacks. Whether you’re restocking for ongoing maintenance work or ordering against a project deadline, having a reliable 40mm2 aluminium lug ready to go helps keep crews productive and downtime to a minimum—backed by fast local pick-up or delivery through a dedicated trade supplier.

Key Specs

• Nominal Conductor Size: 40mm²

• Stud Size: 12mm

• Conductor Type: CCT aluminium

• Material: Aluminium (99.6% pure)

• Finish: Tin plated

• Operating Temperature: -20°C to +140°C

Ideal For

• Terminating CCT aluminium overhead conductors

• Utility, infrastructure, and distribution projects

• Electrical contractors working to authority specifications

• Maintenance teams requiring durable, compliant aluminium lugs

• Jobs where reduced rework and long-term reliability matter
