Cabac HEATSHRINK THIN WALL 38MM WHITE XLP38WH x 25

Description

Reliable Electrical Insulation and Cable Protection

The CABAC XLP38WH thin wall heat shrink tubing provides electricians and contractors with a dependable solution for insulating, protecting, and colour coding electrical conductors. Manufactured from flame-retardant electron beam cross-linked polyolefin, this white heat shrink tubing delivers excellent electrical and mechanical protection while helping safeguard cables from environmental exposure.

Designed for professional electrical applications, the tubing shrinks down to approximately 50% of its original diameter when heated, creating a secure and tight-fitting protective layer around cables, joints, and terminals. Its flexible construction makes installation quick and efficient while maintaining long-term durability.

Durable Performance for Demanding Electrical Applications

Built to withstand harsh working environments, CABAC heat shrink tubing offers resistance against common fluids, solvents, abrasion, and UV exposure. With a continuous operating temperature range of -75°C to +135°C, it is suitable for a variety of residential, commercial, and industrial electrical installations.

The XLP range provides reliable insulation performance with a 600V voltage rating and strong physical properties, including high tensile strength and excellent elongation. Its thin wall design allows for easy installation while maintaining effective protection against mechanical stress and environmental factors.

Trade-Ready Heat Shrink Solution from CABAC

The CABAC XLP38WH white heat shrink tube is supplied in a 25m roll, making it ideal for electricians requiring a practical quantity for ongoing installation work. It complies with recognised standards including UL224 VW1 and ASTM D2671, ensuring consistent quality for professional applications.

Available through iSupply Electrical, trades can access reliable CABAC electrical products with competitive trade pricing, fast delivery across Australia, and convenient ordering options for projects of all sizes.

Key Specs

• Brand: CABAC
• Model: XLP38WH
• Colour: White
• Pre-shrink diameter: 38.1mm
• After-shrink diameter: 19.1mm
• Recovered wall thickness: 1mm
• Length: 25m roll
• Material: Electron beam cross-linked polyolefin
• Wall type: Thin wall
• Glue lined: No
• Continuous operating temperature: -75°C to +135°C
• Shrink temperature: >105°C
• Voltage rating: 600V
• Breakdown voltage: 25kV/mm wall thickness
• Tensile strength: 10.4MPa
• Elongation at break: 400%
• Water absorption: 0.15% maximum
• Compliant standards: UL224 VW1, ASTM D2671

Ideal For

• Licensed electricians requiring reliable cable insulation solutions
• Electrical contractors working on residential, commercial, and industrial projects
• Cable identification and colour coding applications
• Protecting electrical joints, terminals, and conductors
• Switchboard and control panel installations
• Maintenance and repair work requiring durable cable protection
• Trade professionals needing compliant electrical accessories in bulk quantities
