Cabac HEATSHRINK THIN WALL 2.4MM BLUE 1.2M XLP2.5BL/4FT

Description

Reliable Electrical Insulation and Protection

The CABAC XLP2.5BL/4FT thin wall heat shrink tubing provides dependable insulation and mechanical protection for electrical conductors in demanding environments. Manufactured from electron beam cross-linked polyolefin, this blue heat shrink sleeve delivers excellent resistance to abrasion, impact, common fluids, and solvents while maintaining flexibility during installation.

Suitable for residential, commercial, and industrial projects, the tubing offers a secure barrier against environmental factors while helping electricians maintain organised and clearly identified cable systems.

Built for Trade Applications

Designed for professional electricians and maintenance teams, this heat shrink tubing shrinks to approximately 50% of its original diameter when heated above 105°C. The result is a tight-fitting seal that enhances cable insulation and improves the overall finish of electrical installations.

Its flame-retardant construction, UV resistance, and 600V rating make it suitable for switchboards, control panels, cable repairs, and general wiring applications. CABAC heat shrink tubing complies with UL224 VW1 and ASTM D2671 standards, ensuring dependable performance across a wide range of projects.

Durable Performance for Australian Worksites

Engineered to withstand harsh conditions, CABAC thin wall heat shrink tubing operates continuously between -75°C and +135°C. It offers strong dielectric properties, excellent tensile strength, and minimal water absorption for long-term reliability.

Available through iSupply Electrical, trade professionals benefit from competitive wholesale pricing, fast Australia-wide delivery, and access to more than 15,000 electrical products to keep projects moving efficiently.

Key Specs

• Brand: CABAC
• Product code: XLP2.5BL/4FT
• Colour: Blue
• Wall type: Thin wall
• Material: Electron beam cross-linked polyolefin
• Pre-shrink diameter: 2.4mm
• After-shrink diameter: 1.2mm
• Recovered wall thickness: 0.48mm
• Length: 1.2m (4ft)
• Operating temperature: -75°C to +135°C
• Shrink temperature: Above 105°C
• Voltage rating: 600V
• Longitudinal shrinkage: Less than 5%
• Tensile strength: 10.4 MPa
• Breakdown voltage: 25kV/mm
• Water absorption: 0.15% maximum
• Glue lined: No
• Standards: UL224 VW1 File No. E366157, ASTM D2671

Ideal For

• Cable insulation and protection
• Colour coding electrical conductors
• Switchboard installations
• Control panels and distribution boards
• Electrical maintenance and repairs
• Commercial and industrial wiring projects
• Residential electrical installations
