Cabac HEATSHRINK DUAL WALL GLUE L 19-6 1.2M XDW20BK

Description

Flexible Dual Wall Heatshrink for Reliable Cable Protection

The CABAC XDW Dual Wall Glue Lined Heatshrink provides a reliable solution for electrical insulation, strain relief, and mechanical protection applications. Manufactured from flexible polyolefin with a modified polyamide adhesive lining, this dual wall heatshrink creates a secure fit around cables and components when heated.

With a high 3:1 shrink ratio, the 19mm pre-shrink diameter reduces to 6mm after shrinking, allowing it to accommodate different cable sizes while maintaining strong coverage. Its flexible construction makes it suitable for installations where movement, vibration, or space limitations are common.

Trade-Grade Adhesive Lined Heatshrink for Electrical Applications

Designed for professional electrical and mechanical applications, the CABAC XDW series features flame retardant properties and excellent mechanical adhesion. The adhesive lining helps hold the tubing securely in place, making it suitable for strain relief on cords, insulation repairs, and general cable protection.

This heatshrink tube is commonly used across electrical, automotive, and maintenance environments where dependable protection is required. While the adhesive layer provides mechanical bonding, it is not designed as a fully waterproof sealing solution. For waterproof joint protection, a dedicated waterproof heatshrink product should be considered.

CABAC Quality for Professional Installations

Built to meet demanding trade requirements, the XDW Dual Wall Glue Lined Heatshrink delivers consistent performance for contractors who need dependable insulation and protection materials. Its compact 1.2m length provides convenient handling and storage while remaining practical for various repair and installation tasks.

Key Specs

• Material: Dual wall flexible flame retarded polyolefin with modified polyamide adhesive sealant
• Colour: Black
• Pre-shrink diameter: 19.1mm
• After-shrink diameter: 6mm
• Heatshrink length: 1.2m
• Shrink ratio: 3:1
• Recovered wall thickness: 2.15mm
• Operating temperature: -55°C to +110°C
• Shrink temperature: Starts at 90°C, completed at 125°C
• Voltage rating: 600V
• Tensile strength: 10.5MPa
• Elongation at break point: 200%
• Breakdown voltage: 20kV/mm wall thickness
• Water absorption: 0.5%
• Standards: UL, MIL-1-23053/4, JIS

Ideal For

• Licensed electricians requiring reliable cable insulation solutions
• Electrical contractors performing repairs and installations
• Maintenance teams protecting cables from mechanical damage
• Strain relief applications on electrical cords
• Insulation repair and cable reinforcement
• Automotive and mechanical protection applications
• Trade professionals needing flexible glue lined heatshrink tubing
