TSTAT 50-320 DEG C SPST + SWITCH 1470MM

Description

Accurate Temperature Control for Demanding Applications

This E.G.O. thermostat delivers dependable temperature regulation across a wide 50–320°C range, making it a solid choice for appliances and equipment where consistent heat control matters. The SPST thermostat is designed to break on temperature rise, helping protect components from overheating while maintaining stable operation. With a smooth start angle of 85° and a full 310° rotation, adjustments are straightforward and precise, saving time during setup and servicing.

Proven E.G.O. Reliability You Can Trust

Built to trade-grade expectations, this thermostat and shaft-mounted switch combination is designed for long-term reliability in residential, commercial, and light industrial environments. Rated at 16A 240V, both the thermostat and the integrated fan switch are suited to demanding electrical loads. The 1470mm capillary with a 156 x 3mm sensor provides flexible installation options, making it easier to position the sensor accurately without compromising performance or compliance.

Installer-Friendly Design That Saves Time on Site

Designed with working electricians and maintenance teams in mind, this unit combines temperature control and fan switching in one compact solution. The single pole shaft-mounted fan switch operates between 30–310° rotation, reducing the need for additional components and simplifying wiring. That means faster installs, fewer parts to source, and less downtime when replacing or upgrading existing controls—ideal when jobs are on tight schedules.

Key Specs

• Temperature range: 50–320°C

• Thermostat type: SPST, break on temperature rise

• Electrical rating: 16A 240V

• Capillary length: 1470mm

• Sensor size: 156 x 3mm

• Start angle: 85°

• Rotation: 310°

• Shaft-mounted fan switch: Single pole, 16A, ON 30–310° rotation

Ideal For

• Appliance repairs and replacements

• Commercial and industrial heating equipment

• Maintenance teams needing reliable temperature control components

• Electricians servicing ovens, heaters, and fan-assisted systems
