Fantech TD Quiet Inline Mixvent Fan 200mm TD-800/200N
$1,028.28 inc GST
The Fantech TD-800/200N delivers compact, dependable inline ventilation with straightforward installation and maintenance access. Its mixed-flow design, two-speed motor, standard 200mm duct compatibility, and tested airflow and noise performance make it a practical choice for professional ventilation projects.
Fast Shipping
On All Orders
Australian Company
Owned & Operated
15+ Years
Industry Experience
Easy Returns
30 Days Peace Of Mind
16 in stock
Description
Fantech TD-800/200N for Efficient Inline Ventilation
The Fantech TD Quiet Inline Mixvent Fan 200mm TD-800/200N combines a compact design with a high-performance mixed-flow impeller for efficient ducted ventilation. Designed for connection to standard 200mm circular ducting, it provides a practical solution where dependable air movement and space-efficient installation are important. Its integrated mounting foot simplifies positioning, while the supplied plug and lead help streamline electrical setup.
The TD-800/200N uses a two-speed squirrel cage capacitor-run motor powered by 230V single-phase supply at 50/60Hz. The fan is wired for high-speed operation and can be adjusted using a VA-type speed controller when required. Sealed ball bearings support reliable operation, while Class B insulation and an IP44 protection rating provide appropriate protection for its intended ventilation environment.
Easy Installation and Maintenance
Designed with trade installation in mind, the Fantech TD-800/200N connects directly to standard circular ducting, helping simplify integration into existing or new ventilation systems. The specially designed support brackets allow the fan assembly to be removed for maintenance or repair without disrupting the duct system. This can help reduce service time and minimise unnecessary work during maintenance.
Its reinforced, moulded polypropylene housing provides a practical and durable construction, while the injection-moulded plastic mixed-flow impeller supports consistent fan operation. The compact inline configuration also allows flexible installation in different positions.
Tested for Professional Ventilation Applications
The TD-800/200N has airflow performance tested to ISO5801 Part 1, 1997 and AMCA 210-99 standards. Noise testing has been carried out to BS848 Part 2, 1985 standards, providing useful performance information for professionals selecting equipment for ducted ventilation installations.
Key Specs
- Model: TD-800/200N
- Duct diameter: 200mm
- Fan type: Inline mixed-flow
- Motor: 2-speed squirrel cage, capacitor run
- Power supply: 230V, single-phase, 50/60Hz
- Bearings: Sealed ball bearings
- Insulation class: B
- Protection rating: IP44
- Housing: Reinforced moulded polypropylene plastic
- Impeller: Injection-moulded plastic
- Speed control: VA-type speed controllers
- Airflow testing: ISO5801 Part 1, 1997 and AMCA 210-99
- Noise testing: BS848 Part 2, 1985
Ideal For
- Licensed electricians installing ventilation systems
- HVAC and mechanical contractors
- Residential ducted ventilation projects
- Commercial ventilation installations
- Maintenance and replacement work
- Applications using standard 200mm circular ducting
- Projects requiring accessible fan maintenance
