FANTECHTRADE ProVent In-Line Duct Mounted Provent series 150mm Timmer FANRIL-150TSW

Description

High Performance Ventilation for Trade Installations

Designed to deliver powerful airflow with low operating noise, the ProVent RIL-150TSW utilises a high-performance mixed-flow impeller driven by a reliable two-speed capacitor run motor. The adjustable run-on timer allows continued ventilation after switching off, helping remove excess moisture, heat, and odours from bathrooms, laundries, kitchens, workshops, and other enclosed spaces.

Its IP44-rated construction makes it suitable for demanding ventilation applications while complying with relevant Australian performance standards.

Fast Installation and Easy Maintenance

The integrated mounting foot and supplied plug and lead simplify installation, helping electricians reduce installation time on-site. Specially designed support brackets allow the fan assembly to be removed without disturbing the ductwork, making routine servicing and maintenance significantly easier.

The fan can also be mounted in any position, providing flexibility across a wide range of residential and commercial duct layouts.

Built for Reliable Australian Projects

Manufactured using reinforced injection moulded polypropylene housing and a durable mixed-flow impeller, the RIL-150TSW is designed for continuous reliability. Manual-reset thermal overload protection provides additional motor protection, while the external two-speed switch gives installers greater airflow flexibility to suit varying project requirements.

Whether you’re completing new builds, renovations, or commercial ventilation upgrades, this Fantech inline fan offers dependable performance trusted by Australian trade professionals.

Key Specifications

• 150mm inline mixed-flow duct fan
• Adjustable 1–30 minute run-on timer
• External two-speed switch included
• High-performance mixed-flow impeller
• Reinforced polypropylene housing
• Injection moulded plastic impeller
• 230V single-phase, 50Hz motor
• IP44 rated
• Class B insulation
• Ball bearing motor
• Manual-reset thermal overload protection
• Integrated mounting foot
• Plug and lead included
• Removable motor assembly for easy servicing
• Suitable for supply or exhaust air applications
• Mountable in any position
• Designed to Australian standards

Ideal For

• Licensed electricians
• HVAC installers
• Commercial ventilation projects
• Residential exhaust systems
• Bathroom and laundry ventilation
• Kitchen exhaust applications
• Workshops and light industrial buildings
• Building maintenance contractors
• Facilities management
• New construction and renovation projects
