Fantech TD Silent Exhaust Fan High Capacity W248mm TD-1300/250SIL

Description

The TD Silent Series of low-profile mixed-flow in-line fans features advanced noise reduction technology, resulting in exceptionally quiet operation. This quiet performance is achieved through a sophisticated internal design that maintains excellent airflow efficiency without compromising sound levels. The series includes six models with spigot sizes ranging from 100 to 315mm.

Features:

High-performance mixed-flow impeller.
Operates with minimal noise.
Advanced design includes vibration-absorbing elements.
360° rotating junction box simplifies power cable connection (available for 100, 125, 150, and 200mm models only).
Integral mounting foot facilitates easier installation.
1 to 30-minute run-on timer available for 100 to 200mm models.
Plug and lead included for straightforward installation.
Convenient 2-speed motor, preset to high speed (single-speed for models with run-on timer).
Fan body can be removed easily without affecting the connected ductwork.
Construction:

Casings made from epoxy-coated steel.
Impellers constructed from aluminum with a mixed-flow design.
Motor:

Standard models: 2-speed, squirrel cage induction motor.
Models with run-on timer: Single-speed, squirrel cage induction motor.
Power Supply: 230V, single-phase, 50Hz.
Bearings: Sealed ball bearings, lifetime lubricated.
Speed control via VA type speed controllers (available only in high speed for non-timer models).
Insulation Class: B.
Protection Rating: IP44.
Internal Protection:

Manual-reset thermal overload protection, meeting AS/NZS60335-2-80:2004 standards for in-line fans.
Testing:

Airflow tested to ISO5801: Part 1, 1997 and AMCA 210-99 standards.
Noise tested to ISO 13347-3, 2004 standards.
