Flashview HDMI Extender Over CAT6 (50m) HDMI-EXT50M

Description

The HDMI-EXT50M transmits HDMI video/audio over distances up to 50m over CAT6 cable. This extender is a reliable and convenient device that allows a HDMI source to be outputted to a distant display. Perfect for displays in lecture halls, home theatres, retail environments, clubs, business foyers and data control centres.

Product features:

• Transmit HDMI signal over 50m via single CAT6 cable without signal loss

• Supports up to Full HD 1080p resolution

• Supports 3D video formats

• Transmit up to 60m via CAT6, 50m via CAT5E or 40m via CAT5

• Up to 225MHz/2.5Gps bandwidth

• Easy plug-and-play installation

• Includes 2 x 5VDC 1A power supply

Includes:

1 x HDMI Transmitter

1 x HDMI Receiver

2 x Power supply

1 x User manual

SPECIFICATIONS

General:

Resolution: 1080p (1920 x 1080)

HDMI Format: 480i / 480p / 576i / 576p / 720i / 720p / 1080i / 1080p

Support Video Colour Format: 24bit / 30bit / 36bit /48bit dark colour

Support Audio Format: DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD(HBR)

Support Blu-ray: DVD24 / 50 / 60fs / HD-DVD / XVYCC

Ethernet:

Ethernet Interface: RJ45

Ethernet Transmission Distance: 50m via CAT6 / 50m via CAT5E / 40m via CAT5

Max. Data Rate: 2.5Gbps

Max. Pixel Clock: 225MHz

Environmental:

Power Supply: 5VDC / 1A

Operating Environment: -5°C~+70°C / 5~95% RH

Warranty (Years): 1

Shipping Weight and Dimensions

Includes product packaging

Width: 220 mm

Height: 55 mm

Depth: 155 mm

Weight: 0.50 kg
