The JetVent Airmover is designed to enhance air circulation in large enclosed spaces like warehouses and recreational facilities. Mounted from the ceiling, it creates a cross-flow of air that improves heat transfer between the air and the human body, contributing to a more comfortable and refreshing environment.
Features:
Prevents the accumulation of hot, stagnant, and polluted air.
Provides a gentle breeze with minimal disruption to the work environment.
High mounting position avoids interference with equipment operations.
Adjustable discharge nozzle allows for customized air flow direction.
Equipped with a high-performance backward-curved centrifugal fan.
Available with both single-phase and three-phase motors.
The single-phase unit includes a speed controller and a 3-pin plug with lead. The three-phase unit can be speed-controlled with a Star/Delta 2-speed switch.
Constructed from durable galvanized steel with a grey powder-coated finish.
For installations near the ceiling, a model with an inlet on the underside is available.
Other color options can be provided.
Construction:
Grey, powder-coated galvanized steel housing.
Adjustable discharge nozzle.
Backward-curved centrifugal impeller.
Motor:
Type: External rotor, squirrel cage induction motor.
Electricity supply: 220-240V, single-phase, 50Hz; 415V, three-phase, 50Hz.
Bearings: Sealed-for-life, ball.
Single-phase motor: Speed-controllable.
Three-phase motor: Can be set to high or low speed, with optional star/delta switch available.
Isolator switch installed on the fan.
Internal Protection:
Comes standard with internal thermal protection on all units.
